Vertical Lifting Flexible Screw Feeder Spiral Elevator Conveyor
1) Compact structure, saving floor space;
2) Economical ,simplify processing technology, enhancing productivity;
3) Easy to install and maintain
4) The spiral conveyor less than 10m can be made as a whole and only need one motor.
5) Can widely used in beverage, food , daily commodity, pharmaceutical and logistics etc industry ;
6) Working principle: from different floors vertical transport,the conveying products are mainly plastic box,carbons,cases and packed items;
7) One motor for the spiral conveyor regarding the floor height difference less than 10m.
8) Uplifting or down transport,Max load: 50Kg/m,Max speed: 60m/min,Angle:7 -15°
Vertical Lift Elevator Specification:
Infeed Height: | Customized |
Out-feed Height: | Max Height 10 Meters |
Chain Width: | 304.8mm, 406.4mm, 609.6mm |
Conveyor Speed: | Max 60 m/min (customized) |
Application: | Cosmetic/Food/Beverage/Packaging Industry,etc |
Advantage: | We have our own injection modling facory |
Delivery: | 30-40 days after downpayement |
Warranty: | 1 year (except human factor) |
Motor brand: | SEW or Made in China or customized |
Test: | working 24 hours for testing |
| Spiral Type: | Motor Drive Spiral Conveyor, Gravity Roller Spiral Conveyor |
| Applicable Products: | Carton Box, Basket, Big Barrel,Film Shrink Wrap Case,Pouches, Bags,etc |
| Conveying Height: | 1m ~ 20m (As Client Fact Need Customize) |
| Conveying Speed: | 1m ~ 40m/min (Adjustable Speed) |
| Conveying Direction: | Up to Down, Down to Up |
| Height of Outlet and Inlet: | Standard Outlet/Inlet Height is 800mm(As Fact Need Customize) |
| Conveyor Width: | 100mm ~500mm (As Client Fact Need to Customize) |
| Conveyor Chain Types: | Anti-skid Conveyor Chains, Stainless Steel Rollers, Mesh Conveyor Chains, Flexible Keel Chains,etc |
| Conveyor Frame Material: | Spray-paint Carbon Steel, Aluminum Profile Frame |
| Drive Motor: | OMAT, SEW |
| Drive Mode: | Gear Motor Drive Mode, Electric Roller Drive Mode,etc |
| Speed Regulation Mode: | Variable Frequency Speed Regulation, Step-less Speed Change, etc. |
| Auxiliary Functions: | Automatic Lubrication and Automatic Tensioning Device |
The Single Lane Spiral Conveyor consists of 4 standard Models and Types that can be customized and modified in the field to accommodate emerging needs and requirements. Every model and type includes a guiding system including precision low friction bearings. The slats run free from supports so there’s only rolling friction. No lubrication is needed that results in a low noise level and clean transport. All of this makes it possible to design the Spiral Conveyor with only one motor. This saves a lot of energy and low maintenance is required.
Multiple applications
Spiral Conveyor Machine have wide application range,could lifting up or lift down according to the conveyor chains surface. It can effectively avoid leading to products dumping and damage, when running in too large angle, and realize the demand of continuous safety lift up or Lift down products, and the equipment control is simple. It can simplify the production process and improve the production efficiency. There are multiple applications suitable for the Single Lane Spiral Conveyor such as; bags, bundles, totes, trays, cans, bottles, containers, cartons and wrapped and unwrapped items.
|
|
